Unmistakable. Powerful. Flexible.
blueplanet 50.0 NX3 / 60.0 NX3
Your benefits at a glance
- Very flexible due to 5 MPP trackers for complex system designs
- High energy yield through 150% oversizing of PV generator
- Special properties for extreme environmental conditions
- Lean commissioning and updates via App
- Compatible with bifacial and high power PV modules
Technical Highlights
Efficient Max. efficiency 98,2% +++ Active cooling +++ Self-consumption <1W +++ Wide DC voltage window: min. 200 V, max. 1000 V +++ Shade management – improved generation under non-ideal conditions
Flexible Two power ratings: 50 kVA / 60 kVA for particularly complex roof tops (incl. retrofit) +++ 5 MPPTs for flexible PV system design (2 strings per MPPT) +++ 40 A / 32 A input current per MPPT
Reliable IP66 rating for outdoor use +++ Integrated DC-switch +++ International standards +++ With 4K4H climatic category for harsh environments +++ Zero feed-in function
Smart High number of communication options: LAN/ WiFi/ RS485 +++ Plug & Play concept +++ Smart monitoring via App
Convenient Lightweight: 45 kg +++ Only basic tools needed +++ SUNCLIX connectors +++ No need to open lid +++ Compact, wall-mounted design
