Powador-web

The Ultraverter system combines the best features of DC optimizers, string inverters and micro-inverters in one advanced concept.
It comes with a completely new "AC series connection" system architecture. Ultraverters are suitable for residential, as well as medium-scale, commercial solar power plants.

PREVIEW. Initially available on the US-American market from the end of 2015 onwards.

The Powador 2002 to 6002 solar PV inverters are single-phase units with transformer and AC powers ranging from 1.65 kVA, 2.5 kVA, 3.5 kVA,
4.2 kVA to 5.0 kVA.

They feature easy system design, effortless installation and highest degrees of efficiency for residential solar power plants.

The Powador 3200 to Powador 6600 solar PV inverters are transformerless, single-phase units with AC powers ranging from 2.6 kVA, 3.45 kVA, 3.6 kVA, 4.4 kVA, 4.6 kVA to 5.5 kVA.

They are the first choice when it comes to designing residential solar power plants with easy installation and maintenance in mind.

The blueplanet TL1 fulfil each and every requirement expected of modern solar PV inverters for use in residential PV systems: they are light and can be installed quickly; all essential technical features are included in the price; reliable operation and yields are guaranteed.

The blueplanet 5.0 TL3 to 9.0 TL3 solar PV inverters are transformerless, 3-phase units with AC powers ranging from 5.0 kVA, 6.5 kVA, 7.5 kVA to 9.0 kVA.
They are the ideal inverters for the smooth and most efficient design of any residential or small commercial solar power plant.

The Powador 12.0 TL3 to 20.0 TL3 solar PV inverters are transformerless, 3-phase units with AC powers ranging from 10.0 kVA, 12.5 kVA, 15.0 kVA to 17.0 kVA.

They are ideally suited for the decentralized, extremely flexible design of small and medium-sized commercial solar power plants – rooftop or open space applications alike.

The Powador 30.0 TL3 to 60.0 TL3 solar PV inverters are transformerless, 3-phase units with AC powers ranging from 25.0 kVA, 27.5 kVA, 30.0 kVA, 33.3 kVA, 36.0 kVA to 49.9 kVA.

They combine the utmost efficiency with ultimate uptime for decentralized commercial and utility-scale solar power plants.

The blueplanet 50.0 TL3 INT is a compact and reliable solar PV inverter for the development of commercial and industrial-scale solar power plants that feature a decentralized plant concept.
The transformerless, 3-phase unit offers an intelligent design for simple installation: 50 kVA that you can easily wall mount.

The Powador 48.0 TL3 Park and 72.0 TL3 Park are transformerless, 3-phase units with AC powers of 40.0 kVA and 60.0 kVA.
As efficient and flexible as the Powador 30.0 TL3 to 60.0 TL3, these solar PV inverters are ideally suited for connection to the external transformers of decentralised commercial and utility-scale solar power plants.

The Powador 30.0 TL3 to 60.0 TL3 solar PV inverters are transformerless, 3-phase units with AC powers ranging from 25.0 kVA, 27.5 kVA, 30.0 kVA, 33.3 kVA, 36.0 kVA to 49.9 kVA.

They combine the utmost efficiency with ultimate uptime for decentralized commercial and utility-scale solar power plants.

The blueplanet 50.0 TL3 INT is a compact and reliable solar PV inverter for the development of commercial and industrial-scale solar power plants that feature a decentralized plant concept.
The transformerless, 3-phase unit offers an intelligent design for simple installation: 50 kVA that you can easily wall mount.

The Powador 48.0 TL3 Park and 72.0 TL3 Park are transformerless, 3-phase units with AC powers of 40.0 kVA and 60.0 kVA.
As efficient and flexible as the Powador 30.0 TL3 to 60.0 TL3, these solar PV inverters are ideally suited for connection to the external transformers of decentralised commercial and utility-scale solar power plants.

The Powador XP500-HV TL and XP550-HV TL are solar PV inverters with AC powers of 500 kVA and 550 kVA.

As transformerless units, they offer extremely efficient, flexible solutions for centralized designs of commercial and utility-scale solar power plants.

The Powador XP500-HV TL outdoor and XP550-HV TL outdoor are solar PV inverters with AC powers of 500 kVA and 550 kVA.

They are ideal for cost-effective, efficient design of centralized, open space commercial and utility-scale solar power plants.

The blueplanet 750 TL3, 875 TL3 and 1000 TL3 are transformerless solar PV inverters with AC powers of 750 kVA, 875 kVA and 1,000 kVA.
They offer precise, innovative solutions for the centralised design of large commercial and industrial-scale solar power plants.

The Integrated Power Station provides you with the most extensive support in implementing utility-scale solar power plants.
Inverters, medium voltage transformer and disconnection units for the DC and AC side can be mounted together on a single base plate to create a ready-to-use, functional unit.

The blueplanet gridsave eco 5.0 TR1 is THE intelligent energy manager for private, and small-scale commercial purposes – in both grid-parallel and off-grid operation.
As a perfect mediator between the feed-in inverter, the PV system, the lead-based battery and the public grid, it ensures optimum self-consumption of your solar power.

Do you generally have a well-balanced load profile with average demand within your company, and is the energy balance only ruined by a few steep peak demands?
To avoid this, we have designed the blueplanet gridsave 14.0 TL3 bidirectional battery inverter for optimised PV self-consumption and intelligent load management.

The blueplanet gridsave 120 TL3 is a bidirectional battery inverter with an exceptionally high power rating: 120 kW for charging batteries or feeding into the local grid on 3 phases.
It is worth considering for larger commercial applications: for PV self-consumption in industrial complexes and residential estates, or for public and smaller utility companies in order to support local grids.

Powador PV-pilot is our new system design program, which, like its predecessor KACOCALC Pro, you can download for free from our website.

Powador PV-pilot basically works like the autopilot function in an airplane. Simply enter the location of the plant, type and number of modules, and the software tool will automatically find the path to the optimal design – including the projected yield and wiring suggestions.

Powador-web is an Internet portal that allows for a comprehensive evaluation and visualisation of photovoltaic installations. Access is possible from anywhere in the world via the Internet. Access is password protected.

Yield display for a quick overview of your system's performance ability.

The Powador-proLOG is a data logger that provides extensive options for local and remote monitoring on the PC. It records the currents, voltages, temperatures, power and yields of every individual inverter. External sensors can also be connected to it.

The stored installation data is transmitted every day in a text file to an Email address of your choice. The data logger also automatically reports by Email, fax or SMS if the installation exits the operating states specified by the user. The alarm parameters can be matched exactly to the technical properties of the installation.

The Powador-piccoLOG is the compact and cost-effective monitoring and control unit for PV systems from 1 to 20 kWp and for a maximum of three inverters.

The digital inputs extension module is our most cost-effective solution to control the output of solar PV inverters remotely. In this way, photovoltaic systems can contribute to rectifying grid disturbances.
The extension module is available for the following inverters: blueplanet 3.0 TL1 to 5.0 TL1 and blueplanet 5.0 TL3 to 9.0 TL3.

The Powador-go enables the user to measure direct and alternating currents with ease. As an accessory for the large Powador-proLOG data logger, the current sensor has two additional options:
It allows more than 31 inverters to be included in monitoring. It also allows the monitoring of inverters without the RS485 interface with the Powador-proLOG.

Powador-go
Suitable for AC and DC (specify with order)
Galvanically isolated current measurement

Two versions:
Advanced (RS485 not optionally isolated)
Premium (RS485 optionally isolated)

With our Priwatt system for controlling self-consumption you can make use of the electricity generated by your own photovoltaic system yourself. In that way you become more independent in terms of energy supplies and are taking the next step towards the energy turnaround.

Free of charge and pre-installed in all inverter models up to 50 kVA.

The Powador Mini-Argus is an external generator junction box for the M version of the Powador 30.0 TL3 to 39.0 TL3 inverters.

Use of the Powador Mini-Argus makes it possible to combine the module strings near the PV modules.

External generator junction box with string fuse, overvoltage protection and DC disconnector.

External generator junction box with string fuse, overvoltage protection and DC disconnector.

The K 150 has a continuous rated power
of 150 W and is available for input voltages
of 12 - 230 V.

The K 200 has a continuous rated power
of 200 W and is available for input voltages
of 12 - 230 V.

The K 500N has a continuous rated power
of 500 W and is available for input voltages
of 12 - 230 V.

The K 1000 has a continuous rated power
of 1000 W and is available for input voltages
of 24 - 230 V.

The K 3000 has a continuous rated power
of 3000 W and is available for input voltages
of 24 - 230 V.

The K 1808 has a continuous rated power
of 1800 W and is available for input voltages
of 24 - 750 V.

The LGP 3001N2 has a continuous output power of 3000 W and an input voltage of 230 V.

The single-phase charging rectifier with up to 800VDC output voltage.

The LGI2001 makes available a charging power of 2 kW. Active power factor correction (PFC) provides for sinusoidal power consumption.

With efficient regulation, the KPF3301 makes available up to 3.3 kW of charging or discharging power with a one-phase power supply.

The LGP3001bi makes available a charging power of 3 kW. Active power factor correction (PFC) provides for sinusoidal power consumption.

With efficient regulation, the LGI6501 makes available up to 3.3 kW of charging power with a one-phase power supply and up to 6.5 kW of charging power with a three-phase power supply.

The PWD 506 has a continuous rated power of 500 W and is available for input voltages and output voltages of 24 - 220 V.

The PWD 1206 has a continuous rated power of 1200 W and is available for input voltages and output voltages of 24 - 220 V.

The PWD 2006 has a continuous rated power of 2000 W and is available for input voltages and output voltages of 24 - 220 V.

The PWD 3006 has a continuous rated power of 3000 W and is available for input voltages and output voltages of 24 - 220 V.

On customer request KACO produces frequency converters with a nominal power between 200 W and 10 kW.
